Features: Controllable angle 180°, All- metal gear
Model No.: HD3216LV
Motor type: Core motor
Dead band: 2μs
Neutral Position: 1500μs/330hz
Remote control Angle: 90-120°±2°
500-2500μs Angle: 180°±2°
Voltage range: 4.8V-6.0V
Operating Speed(4.8V): 0.14''/60°
Operating Speed(6.0V): 0.11''/60°
Stall Torque(4.8V): 12 kg.cm
Stall Torque(6.0V): 16 kg.cm
Dimensions: 40.5X20X40.5 mm
Weight: 57 g
Connector Wire Length: JR 260 mm
Bearing: 2BB
